| 無線網路 | |
|---|---|
| 標準 | Wi-Fi 6 • IEEE 802.11ax/ac/n/a 5 GHz • IEEE 802.11ax/n/b/g 2.4 GHz |
| Wi-Fi 速度 | AX6000 • 5 GHz: 4804Mbps (802.11ax, HE160) • 2.4 GHz: 1148 Mbps (802.11ax) |
| Wi-Fi 範圍 | 3 Bedroom Houses • 4× Dual-Band High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas • Beamforming Concentrates wireless signal strength towards clients to expand WiFi range • High-Power FEM Improves transmission power to strengthen signal coverage |
| Wi-Fi 容量 | High • Dual-Band Allocate devices to different bands for optimal performance • OFDMA Simultaneously communicates with multiple Wi-Fi 6 clients • Airtime Fairness Improves network efficiency by limiting excessive occupation • DFS Access an extra band to reduce congestion • 8 Streams Connect your devices to more bandwidth |
| 運作模式 | • Router Mode • Access Point Mode |
| 安全性 | |
|---|---|
| 網路安全性 | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway HomeShield Security Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner |
| 訪客網路 | • 1× 5 GHz Guest Network • 1× 2.4 GHz Guest Network |
| VPN 伺服器 | • OpenVPN • PPTP • L2TP |
| VPN 用戶端 | • OpenVPN • PPTP • L2TP |
| Wi-Fi 加密 | • WPA3*6 • WPA2 • WPA • WPA/WPA2-Enterprise (802.1x) |
| 硬體規格 | |
|---|---|
| 網路孔 | • 1× 2.5 Gigabit WAN/LAN Port • 1× Gigabit WAN/LAN Port • 3× Gigabit LAN Ports |
| 支援 USB | 1× USB 3.0 Port USB Sharing: • FTP Server • Media Server • Samba Server |
| 按鈕 | • LED On/Off and Wi-Fi On/Off Combo Button • WPS Button • Power On/Off Button • Reset Button |
| 電源 | • 12 V/2 A |
| 軟體 | |
|---|---|
| 協定 | • IPv4 • IPv6 |
| 服務工具 | HomeShield |
| OneMesh™ | OneMesh™ Supported Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products. |
| 家長監護 | HomeShield Parental Controls • Custom Profiles • Professional Content Filter Library • Family Time • Bedtime • Off Time • Time Rewards • Family Online Time Ranking • Pause the Internet • Weekly and Monthly Reports |
| WAN 類型 | • Dynamic IP • Static IP • PPPoE • PPTP • L2TP |
| 服務品質 | QoS by Device |
| 雲端服務 | • Auto Firmware Upgrade • OTA Firmware Upgrade • TP-Link ID • DDNS |
| NAT 轉發 | • Port Forwarding • Port Triggering • DMZ • UPnP |
| IPTV | • IGMP Proxy • IGMP Snooping • Bridge • Tag VLAN |
| DHCP | • Address Reservation • DHCP Client List • Server |
| DDNS | • TP-Link • NO-IP • DynDNS |
| 管理 | • Tether App • Webpage |
| 其他 | |
|---|---|
| 系統需求 | Internet Explorer 11 , Firefox 12.0 , Chrome 20.0 , Safari 4.0 , or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
| 認證 | CE, RoHS, JPA JRF VCCI |
| 環境 | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Operating Humidity: 10%~90% non-condensing |
| 測試數據 | |
|---|---|
| Wi-Fi 傳輸功率 | CE: <23dBm (5.15GHz~5.35GHz) <30dBm (5.47GHz~5.71GHz) <20dBm (2.4GHz) |
| Wi-Fi 接收靈敏度 | • 2.4 GHz: 11ac VHT20 MCS0: -96dBm, 11ac VHT20 MCS8: -73dBm, 11ac VHT40 MCS0: -94dBm, 11ac VHT40 MCS9: -68dBm, 11ax HE20 MCS0: -95dBm, 11ax HE20 MCS11: -66dBm, 11ax HE40 MCS0: -93dBm, 11ac HE40 MCS11: -63dBm • 5 GHz: 11ac VHT20 MCS0: -94dBm, 11ac VHT20 MCS8: -70dBm, 11ac VHT40 MCS0: -91dBm, 11ac VHT40 MCS9: -67dBm, 11ac VHT80 MCS0: -88dBm, 11ac VHT80 MCS9: -63dBm, 11ax HE20 MCS0: -94dBm, 11ax HE20 MCS11: -64dBm, 11ax HE40 MCS0: -91dBm, 11ax HE40 MCS11: -61dBm, 11ax HE80 MCS0: -88dBm, 11ax HE80 MCS11: -58dBm, 11ax HE160 MCS0: -84dBm, 11ax HE160 MCS11: -55dBm |
| 實體 | |
|---|---|
| 體積 (W×D×H) | 7.9 × 7.4 × 2.3 in (200 × 189 × 59 mm) |
| 包裝內容 | • Wi-Fi Router Archer AX80 • Power Adapter • RJ45 Ethernet Cable • Quick Installation Guide |
